Jiaxing Seaman Marine Co.,Ltd.
Jiaxing Seaman Marine Co.,Ltd. One Stop Soluton For Marine Safety Equipments
Add to Cart
Mobile Trolly Type Marine Fire Extinguisher Wheel 45L Foam For Ship Fire - Fighting
Products Introduction:
Wheel fire extinguishers usually are used to put out the fires from books, oil,archives, expensive
equipment and precision instrument which working below 600 v electrical equipment . Being apply to the
fire of class B from oil products ,They are also used to go out to class A . But excepter for inflammable
liquid ,water-soluble flammable ancharged equipment.
Application:
It is an active fire protection device used to extinguish or control small fires, often in emergency situations.
Feature:
a). High extinguishing efficiency
b). Easy to operate and maintain
c). Corrosion-resistant and long time to use
d). External epoxy paint adds extra protection to withstand extreme temperatures
e). CO2 valve with CE approval to ensure reliability and optimize efficiency
f). No danger or toxin to people or environment
Types of fire extinguishers:
Cartridge-operated extinguishers
It contain the expellant gas in a separate cartridge that is punctured prior to discharge, exposing the propellant to the extinguishing agent.
Specifications:
| code | Specification | out-diameter | Volume | Extinguiher | Max working pressure | Min | Fire class | Packing |
| SM04-250-00 | 25 | 270 | 30 | 55 | 14Bar | 2.5 | 55A1BC | 20×21×35 |
| SM04-500-00 | 50 | 320 | 59 | 93 | 14Bar | 3.0 | 55A11BC | 30×30×29 |
| SM04-1000-00 | 100 | 406 | 124 | 160 | 14Bar | 3.0 | 55A11BC | 33×33×36 |
| SM05-25-00 | 25 | 219 | 30 | 83 | 174Bar | 6.0 | 89BC | 65.5×92×156 |
| SM05-50-00 | 50 | 219×2 | 50 | 83×2 | 174Bar | 6.0 | 89BC | 65.5×92×156×2 |
Photos:
